1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration

Product Categories
Shenzhen Jiangfan Communication Equipment Co., Ltd.
Contact Now

1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration

Brand Name : GAPHO

Model Number : Mini Optical Switch

Place of Origin : China

MOQ : 50

Price : negotiate

Payment Terms : D/P, T/T

Supply Ability : 10000

Delivery Time : 7-10 day

Packaging Details : Carton

Operating Wavelength (nm) : 850&1310±40 ; 1260~1650

Insertion Loss (dB) : ≤1.0; ≤1.2

Dimension (L×W×H) (mm) : 67×25×10

Fiber Length (m) : Customer Specify

Fiber Type : SMF-28

Storage Temperature (℃) : -40～85

Operating Temperature (℃) : -5～70

Contact Now

1x4,1×8 Optical Switch 1260~1650nm ,SMF-28,for Transmitter and Receiver Protection ,Network Test

Description:

1X8 Fiber Optical Switches Modules is a kind of functional component, with the ability of switching optical route.The 1X8 Opto-Mechanical Optical Switches consists of 1 input and 8 output fiber ports that selectively transmits,redirects,or blocks optical power in a fiber optic transmission line.These all-optical switches are bi-directional and can be used in either the 1X8 or 8x1 direction.Fiber optical switches is designed for use in optical fiber communication networks and measurement instruments.

Feature:

  • Unmatched Low Cost
  • Low Insertion Loss
  • High Channel Isolation
  • Highly Stable and Reliable
  • Epoxy-Free Optical path
  • Latching or Non-Latching

Application:

  • Optical Netrwork Protection/Restoration
  • Optical Signal Routing
  • Configurable Optical Add/Drop
  • Transmitter and Receiver Protection
  • Network Test Systems
  • Instrumentation

Performance:

Parameter Specification
Operating Wavelength (nm) 850&1310±40 1260~1650
Insertion Loss (dB) ≤1.0 ≤1.2
WDL (dB) ≤0.25 ≤0.30
PDL (dB) ≤0.1
Channel Cross Talk (dB) ≥40 ≥55
Repeatability (dB) ±0.02
Return loss (dB) ≥35 ≥55
Switching Speed (ms) ≤10
Drive Voltage (V) 5
Power Handing (mW) 500
Durability (Cycles) 10 Million
Switching Type Latching or Non-latching
Operating Temperature (℃) -5～70
Storage Temperature (℃) -40～85
Fiber Type SMF-28
Fiber Length (m) Customer Specify
Dimension (L×W×H) (mm) 67×25×10

Dimensions

1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration

Ordering Information:MOSW－1×8－A－B－C－D－E－F－G

A B C D E F G
Mode Wavelength Voltage Control Model Fiber Diameter Fiber Length Connector

SM:9/125um

M5: 50/125um

M6: 62.5/125um

85: 850nm

13: 1310nm

14: 1490nm

15: 1550nm

162: 1625nm

165: 1650nm

13/15:1310/1550nm

3: 3V

5: 5V

L: Latching

N:Non-Latching

25:250um

90:900um

20:2.0mm

30: 3.0mm

05:0.5m

10:1.0m

15:1.5m

OO:None

FP: FC/PC

FA: FC/APC

SP: SC/PC

SA: SC/APC

LP: LC/PC

LA: LC/APC

1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration

1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration



1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration

1x4 1650nm Fiber Optical Switch SMF-28 For Network Restoration
