Features
l Low Insertion loss
l High Return loss
l Wide Operating Wavelength range
l High Channel Isolation
l High Stability and reliability
l Epoxy-free on Optical Path
Applications
l System Monitoring
l WDM Network
l Transmitters and Fiber Lasers
l Fiber Optical amplifier
l Fiber Optic Instruments
| Performance Specifications |
| Parameter | Specification |
| Channel Wavelength (nm) | 1270 ~ 1611 |
| Center wavelength Accuracy (nm) | ±0.5 |
| Channel Spacing (nm) | 20 |
| Channel Passband (@-0.5dB bandwidth (nm) | >13 |
| Pass Channel Insertion Loss (dB) | ≤0.6 |
| Reflection Channel Insertion Loss (dB) | ≤0.4 |
| Channel Ripple (dB) | <0.3 |
| Isolation (dB) | Adjacent | >30 |
| Non-adjacent | >40 |
| Inertion Loss Temperature Sensitivity (dB/℃) | <0.005 |
| Wavelength Temperature Shifting (nm/℃) | <0.002 |
| Polarization Dependent Loss (dB) | <0.1 |
| Polarization Mode Dispersion | <0.1 |
| Directivity (dB) | >50 |
| Return Loss (dB) | >45 |
| Maximum Power Handling (mW) | 300 |
| Opterating Temperature (℃) | -25~+75 |
| Storage Temperature (℃) | -40~85 |
| Package dimension (mm) | Φ5.5x34 (L38 for 900um Loose tube) |
FQA
1. Q : Are you manufacturer ?
A: yes, we are manufacturer in Shenzhen,China
2. Q : What's your MOQ ?
A: MOQ can be 1 pcs , but we are not suggest to order 1 pcs , because the cost will be higher , so that the price will be higher than your budget .
3. Q : What's the price ?
A : The price is according to your quantity . After you let us know your quantity , we will offer our best price for you . Big Quantity will get very competitive price .
4. Q: Can you quote FOB price ?
A : yes we can , But due to the size and weight is not big , most are delivery by air ,DHL , TNT , UPC , FEDEX ,etc . So it it difficult to do FOB price . The best way is let us know your detailed specifications and quantity , we will offer the freight with products price for your reference .
